Product Details
Place of Origin: CHINA
Brand Name: TORUI
Certification: ISO
Model Number: QT8-15
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Customized
Delivery Time: 30-35 Work Days
Supply Ability: 30 set/month
Dimension: |
3800*2200*2950mm |
Power: |
45kw |
Weight: |
10.5T |
Vibration Force: |
70-100KN |
Molding Area: |
936*880 |
Mixer Model: |
JS750 |
Water Consumption: |
7-10T/day |
Pallet Size: |
1050*900*25/30mm |
Dimension: |
3800*2200*2950mm |
Power: |
45kw |
Weight: |
10.5T |
Vibration Force: |
70-100KN |
Molding Area: |
936*880 |
Mixer Model: |
JS750 |
Water Consumption: |
7-10T/day |
Pallet Size: |
1050*900*25/30mm |
Functions and features
1. Mobility: the ability to easily carry out brick making operations in different locations;
2. Degree of automation: some models are equipped with semi-automatic or fully-automatic operation functions to improve production efficiency;
3. Wide range of applicable materials: bricks can be made from a wide range of materials such as cement and fly ash;
4. Various moulding methods: it can produce different types of brick products such as hollow bricks, solid bricks and blocks;
5. Easy to operate: easy for operators to learn and master;
6. Smaller volume: it occupies less space and requires less space.
Main technical Parameter
| Dimension of host machine | 3800*2200*2950mm | Host machine power | 45kw |
| Weight of host machine | 10.5T | Vibration force | 70-100KN |
| Molding area | 936x880 | Mixer model | JS750 |
| Water consumption | 7-10Ton/day | Pallet size | 1050x900x25/30mm |
| workshop area | 300 m2 | Voltage | adopt to local voltage |
Theoretical production capacity
| Size(LxWxH) | Pcs/Mould | Pcs/Hour | Pcs/Shift |
| 400x200x200mm | 8 | 1440-1920 | 11520-15360 |
| 400x100x200mm | 16 | 2880-3360 | 23040-26880 |
| 240x115x53mm | 45 | 9529-13500 | 76232-108000 |
| 200x100x60mm | 28 | 5040 | 40320 |
| 200x163x60mm | 20 | 3600 | 28800 |
